Stone Washer Introduction stone washer:
This series screw stone washing machine is mainly used for washing material after crushed. Small particles suspended in water flow out through outlet, coarse particles sink down to bottom groove. This stone washing machine also can be used for desliming, dewatering and wash-dressing mineral ore. This machine bears the features of simple structure, easy maintenance, long-term continuous running, good adaptability and big capacity etc. So it can meet the needs of modern large-scale industry production.

Working principle of stone washer:
The stone washer mainly consists of groove, reducer, motor, central shaft, screw blade, and trestle, etc.
This machine is slope installation, the gravel is feed into groove through inlet (inlet position will be defined by user), it forms a settling tank at the bottom of groove, by the action of particles’ different settle speed in media, fine and light particle float on settling tank surface layer, then discharged from outlet, but big and heavy particles settle down, then be taken to the top outlet by screw. So the material is cleaned.

Features and Benefits of stone washer：
1. Simple structure, reliable operation;
2. Convenient maintenance, long-term continuous running;
3. Strong adaptability and big capacity.

Main Technical Parameters of stone washer:

Note:if you want to know more about the stone washer,please submit your requiremengts to us,we will contact you as soon as possible.Welcome to our company.
